Solar Charge Contoller Builtin LED Driver SDN 40 W



Informasi Stok:


Harga Total:

SPESIFIKASI

- Model : SDN-40W

- Sysytem voltage : 12V/24V auto ( 7V ~34V )

- Output power  : 40W

- Output voltage : (Vin+5V) ~66V

- Output waveform : 600mV

- Max input current : 10A

- Max output current  : 2.0A

- Output Costant current precision : <3% (typical) , above 80% rated power<1%

- Typical efficiency : 92~96%

- Work temperature : -35 ~ 55C (-40 ~ 90C customized )

- No load current :  5 ~ 18mA

- Temperature compensation : -5mV/2V (charge voltage,over discharge voltage compensation)

- Contol mode : PWM charge mode , Output Constant Current:PWM+smart High Frequency Modulation software

- Appearance size : 88*53*21mm

- Installation size : 81x40mm

- Install Hole Size : 3

- Weight : 0.14 kg
